Another testing method is ground penetrating radar. It pulses electromagnetic wave technology into the pavement and then ceases the transmission during which the transmitter-receiver detects signals that are deflected from the pavement. Yet another method is the epoxy/core test, which confirms void presence by visual and mechanical methods. It consists of drilling a 25 to 50 millimeter hole through the pavement and into the sub-base with a dry-bit roto-hammer. Next, a two-part epoxy is poured into the hole that is dyed for visual clarity. Once the epoxy is hardened, the technicians drill through the hole. If a void is present, the epoxy will stick to the core and provide physical evidence.
Common stabilization materials are pozzolan-cement grout and polyurethane. The requirements for slab stabilization are strength and the ability to flow into or expand to fill small voids. Colloidal mixing equipment is necessary to use the pozzolan-cement grouts. The contractor should place the grout using a positive-displacement injection pump or a non-pulsing progressive cavity pump. A drill is also necessary but it must produce a clean hole with no surface spalling or breakouts. The injection devices must include a grout packer that is capable of sealing a hole. The injection device must also have a return hose or a fast-control reverse switch in case workers detect slab movement on the uplift gauge. The uplift beam helps to monitor the slab deflection and has to have sensitive dial gauges.
